CUSTOM WORKHOLDING SYSTEMS, DESIGNED & BUILT BY MACRO MACHINE INC.

HYDRAULIC CLAMPING FIXTURE

HORIZONTAL MACHINING CENTER APPLICATION

FEATURES:

• Four Parts On

• Stay Connected

• Internal Manifold Porting

• Double Acting Cylinders

• Sequencing

• Air Check Nesting

HYDRAULIC CLAMPING FIXTURE

HORIZONTAL MACHINING CENTER APPLICATION

FEATURES:

• Eight Parts On

• Disconnect Hydraulic Coupler

• Internal Center Mounted Accumulator

• Single Acting Cylinders

• Individual Face Clamping

HYDRAULIC CLAMPING FIXTURE

HORIZONTAL MACHINING CENTER APPLICATION

FEATURES:

• Disconnect Hydraulic Source Line

• Single Acting Cylinders

• Internally Manifold Ported

• Two Parts On

HYDRAULIC CLAMPING FIXTURE

VERTICAL MACHINING CENTER APPLICATION

FEATURES:

• Twelve Parts On

• Double Acting Swing Cylinders

• Internally Manifold Ported

• Stay Connected

• Auto Tilting Trunion Table

• Air Blow To Tilting Table

PNEUMATIC CLAMPING FIXTURE

VERTICAL MACHINING CENTER APPLICATION

FEATURES:

• Six Parts On

• Stay Connected

• Integrated Tool Touch Sensor

• Stainless Steel Chip Shields

MANUAL CLAMPING FIXTURE

HORIZONTAL MACHINING CENTER APPLICATION

FEATURES:

• One Pin Swing Down Clamp Arm

• One Screw Clamping Applies Three Point Force

MANUAL CLAMPING FIXTURE

VERTICAL MACHINING CENTER APPLICATION

FEATURES:

• Eight Parts On

• Part Family Capable

MANUAL CLAMPING FIXTURE

VERTICAL MACHINING CENTER APPLICATION

FEATURES:

• Multi Step Locators For Product Family

• Interchangeable Studs and C Washers

• Ball Lock Plate Locators

FACE PLATE FIXTURE

CNC LATHE APPLICATION

FEATURES:

• Disc Spring Under Locating Pins

• Draw Bar Connection For Clamping

• Dynamically Balanced
